XS series sand and gravel washing and screening machine

Classification：

Sand washing equipment

Key words:

Message

Product Description
Detailed parameters

- Commodity name: XS series sand and gravel washing and screening machine
Product Introduction

The XS series sand washing machine is a bucket-type washing and screening equipment that can clean and separate stone powder and soil from sand and gravel. It is mainly used for washing, screening, and dewatering construction sand and gravel materials.

Performance Characteristics

Simple structure, convenient maintenance;

Large processing capacity, low power consumption;

Low consumption of wearing parts, low operating cost.

Working Principle

Internal and fully enclosed oil-immersed transmission device

When the XS series sand washing machine is working, the motor drives the impeller to rotate slowly after deceleration through the reducer. The sand and gravel enter the washing tank from the feeding hopper. Under the drive of the impeller, they tumble and grind against each other, removing impurities covering the surface of the sand and gravel, and simultaneously breaking up the water vapor layer covering the sand grains to facilitate dehydration; At the same time, water is added to form a strong water flow, which promptly carries away the impurities and light-weight foreign matters, and discharges them from the overflow port of the washing tank to complete the cleaning process. The clean sand and gravel are carried away by the blades, and finally, the sand and gravel are poured into the discharge hopper from the rotating impeller, completing the cleaning of the sand and gravel.

Model	Bucket Diameter(mm)	Speed (rpm)	Processing Capacity(t/h)	Motor Power(kw)
XS2612	2600	0.8-1.2	30-90	5.5
XS2816	2800	0.8-1.2	60-100	7.5
XS3220	3200	0.8-1.2	90-120	11
XS3622	3600	0.8-1.2	120-160	15
XS4024	4000	0.8-1.2	150-200	18.5
XS4524	4500	0.8-1.2	200-260	22
XS5030	5000	0.8-1.2	250-320	30
